PP-Al2O3-60.0-5.0-AR1004-AR1004

Windows

Windows | PP-Al2O3-60.0-5.0-AR1004-AR1004

€500,00

Qty 5+ > €475,00/piece
Discount will be applied in cart page
If an official quotation is needed or products are not in stock, please send us a request

Only 5 pieces in stock!

This is a Limited Supply product. Availability and order size affect lead time and price.

Substrate material: UV grade sapphire
Diameter: 60.0 mm +0/-0.1 mm
Thickness: 5.0 mm +/-0.1 mm
Wedge, S1: <10 arcsec
Clear aperture: >85%
Surface Quality, S1/S2: MIL 20/10 S/D
Transmitted WFD: λ/6 PV @633nm
Protective chamfers: 0.4 ±0.1 mm at 45deg
Chips: <0.2 mm stoned

Coatings (IBS):
S1: AR≤0.2% @308nm; AOI=0deg;
Overall transmittance >98.5%
S2: AR≤0.2% @308nm; AOI=0deg.

In-stock items ship the next business day via DHL. Estimated delivery time: 1–2 business days (EU), 3–5 business days (Rest of World). View full shipping policy.

OPTOMAN’s UV sapphire windows are specifically engineered to meet the performance and durability needs of these high-energy UV laser environments. Built using high-purity sapphire substrates and coated with advanced Ion Beam Sputtered (IBS) anti-reflective coatings, these windows deliver excellent transmission at 308 nm while maintaining resistance to UV-induced degradation.

These windows are developed to endure repeated cleaning while preserving their optical performance, ultimately reducing replacement frequency and minimizing system downtime.


UV Laser Window, 60 mm Ø × 5 mm thick UV-grade sapphire, offering ≥98.5% transmittance* at 308 nm (AOI = 0°).

*AR≤0.1% @308nm; AOI=0° available upon request
