High Power Thin-Film Polarizers

Many different types of polarizers are available in the market, but there is only one perfectly suitable for high-power laser applications - Thin Film Polarizers. It is a component coated with dielectric multilayers with the main task to separate vertically polarized (s-pol.) from horizontally polarized (p-pol.) light. Thin Film Polarizer completes this task with a high level of efficiency due to negligible absorption within the coating, high transmittance (Tp), and reflectance (Rs).

Quantity discounts: 5pcs – 5% off 10pcs - 15% off 20pcs - 25% off
PP-UVFS-25.4-6.35-TFP95

PP-UVFS-25.4-6.35-TFP95

Type: UV
Dimensions, mm: 25.4
Thickness, mm: 6.35
Coating: HRs > 99.6% + HTp > 95% @ 343 nm
Wavelength, nm: 343
Angle of incidence, °: 45
Flatness, S1 @633 nm: <λ/10 over 15mm area
UNIT PRICE :€240,00
Qty 10+ > €204,00/piece
Available : 6
High Power Thin-Film Polarizers
Sold out

PP-UVFS-46.0-8.0-TFP68-AR681

Type: Ultrafast
Dimensions, mm: 46
Thickness, mm: 8
Coating: Rs>97% & Tp>90% @ 515 nm, Rs>97% & Tp>90% @ 1030 nm
Wavelength, nm: 1030+515
Angle of incidence, °: 45
Flatness, S1 @633 nm: <λ/8 over 10mm area
Available : 0
High Power Thin-Film Polarizers

PP-UVFS-20.0-5.0-TFP78

Type: Standard
Dimensions, mm: 20
Thickness, mm: 5
Coating: Rs>99.9% @ 800 nm + Tp>97% @ 800 nm
Wavelength, nm: 800
Angle of incidence, °: 45
Flatness, S1 @633 nm: <λ/8 over 10mm area
UNIT PRICE :€270,00
Qty 10+ > €229,50/piece
Available : 7
High Power Thin-Film Polarizers

PP-UVFS-12.7-2.3-TFP4535

Type: Standard
Dimensions, mm: 12.7
Thickness, mm: 2.3
Coating: Rs>99.8% @ 1064 nm HTp>99%
Wavelength, nm: 1064
Angle of incidence, °: 45
Flatness, S1 @633 nm: <λ/4 over 6mm area
UNIT PRICE :€70,00
Qty 10+ > €59,50/piece
Available : 10+
High Power Thin-Film Polarizers
Sold out

PLW-DEG1-UVFS-28.6x14.3-3.0-BBTFP10-AR236

Type: Wedge
Dimensions, mm: 28.6x14.3
Thickness, mm: 3
Coating: Ts<20% @ 725 nm - 875 nm, Tp>98% @ 725 nm -875 nm
Wavelength, nm: 725-875
Angle of incidence, °: 70-74
Flatness, S1 @633 nm: <λ/6 over CA
Available : 0
PP-UVFS-50.8-8.0-TFP77

PP-UVFS-50.8-8.0-TFP77

Type: High Power
Dimensions, mm: 50.8
Thickness, mm: 8
Coating: HRs>99.8% @ 532 nm + HTp>97% @ 532 nm
Wavelength, nm: 532
Angle of incidence, °: 45
Flatness, S1 @633 nm: <λ/10 over 15mm area
UNIT PRICE :€630,00
Qty 10+ > €535,50/piece
Available : 4
PP-UVFS-25.4-6.35-TFP77

PP-UVFS-25.4-6.35-TFP77

Type: High Power
Dimensions, mm: 25.4
Thickness, mm: 6.35
Coating: HRs>99.8% @ 532 nm + HTp>97% @ 532 nm
Wavelength, nm: 532
Angle of incidence, °: 45
Flatness, S1 @633 nm: <λ/4 over 7mm area
UNIT PRICE :€210,00
Qty 10+ > €178,50/piece
Available : 10+
High Power Thin-Film Polarizers

PP-UVFS-50.8-8.0-TFP4526

Type: Ultrafast
Dimensions, mm: 50.8
Thickness, mm: 8.0
Coating: Rs>99.9% & Tp>98% @ 1030 nm
Wavelength, nm: 1030
Angle of incidence, °: 45
Flatness, S1 @633 nm: <λ/8 over 15mm area
UNIT PRICE :€580,00
Qty 10+ > €493,00/piece
Available : 1
High Power Thin-Film Polarizers

PP-UVFS-12.7-3.0-TFP67

Type: Ultrafast
Dimensions, mm: 12.7
Thickness, mm: 3
Coating: Rs>99.9% @ 1030 nm + Tp>98% (>99% best efforts) @ 1030 nm
Wavelength, nm: 1030
Angle of incidence, °: 45
Flatness, S1 @633 nm: <λ/3 over CA
UNIT PRICE :€160,00
Qty 10+ > €136,00/piece
Available : 2
High Power Thin-Film Polarizers

PP-UVFS-25.4-6.35-TFP67

Type: Ultrafast
Dimensions, mm: 25.4
Thickness, mm: 6.35
Coating: Rs>99.9% @ 1030 nm + Tp>98% (>99% best efforts) @ 1030 nm
Wavelength, nm: 1030
Angle of incidence, °: 45
Flatness, S1 @633 nm: <λ/4 over CA
UNIT PRICE :€250,00
Qty 10+ > €212,50/piece
Available : 10+
High Power Thin-Film Polarizers
Sold out

PP-UVFS-20.0-5.0-TFP66

Type: Ultrafast
Dimensions, mm: 20
Thickness, mm: 5
Coating: Pol@510-520 nm (Rs>99.0%, Tp>95%)
Wavelength, nm: 515
Angle of incidence, °: 45
Flatness, S1 @633 nm: <λ/10 over 10 mm area
Available : 0
High Power Thin-Film Polarizers

PP-UVFS-50.8-3.0-TFP62-AR619

Type: Standard
Dimensions, mm: 50.8
Thickness, mm: 3
Coating: Tp_avg>97.5%@ 735-755 nm + Rs_avg>97.5%@ 735-755 nm
Wavelength, nm: 735-755
Angle of incidence, °: 45
Flatness, S1 @633 nm: <λ/4 over CA
UNIT PRICE :€980,00
Qty 10+ > €833,00/piece
Available : 6
Product Code Type Dimensions, mm Thickness, mm Coating Wavelength, nm Angle of incidence, ° Flatness Unit Price, EUR Available Quantity Buy
UV 25.4 6.35 HRs > 99.6% + HTp > 95% @ 343 nm 343 45 <λ/10 over 15mm area €240,00
qty 10+ > €204,00 		6
Ultrafast 46 8 Rs>97% & Tp>90% @ 515 nm, Rs>97% & Tp>90% @ 1030 nm 1030+515 45 <λ/8 over 10mm area
0
Standard 20 5 Rs>99.9% @ 800 nm + Tp>97% @ 800 nm 800 45 <λ/8 over 10mm area €270,00
qty 5+ > €256,50 		7
Standard 12.7 2.3 Rs>99.8% @ 1064 nm HTp>99% 1064 45 <λ/4 over 6mm area €70,00
qty 10+ > €59,50 		10+
Wedge 28.6x14.3 3 Ts<20% @ 725 nm - 875 nm, Tp>98% @ 725 nm -875 nm 725-875 70-74 <λ/6 over CA
0
High Power 50.8 8 HRs>99.8% @ 532 nm + HTp>97% @ 532 nm 532 45 <λ/10 over 15mm area €630,00
4
High Power 25.4 6.35 HRs>99.8% @ 532 nm + HTp>97% @ 532 nm 532 45 <λ/4 over 7mm area €210,00
qty 10+ > €178,50 		10+
Ultrafast 50.8 8.0 Rs>99.9% & Tp>98% @ 1030 nm 1030 45 <λ/8 over 15mm area €580,00
1
Ultrafast 12.7 3 Rs>99.9% @ 1030 nm + Tp>98% (>99% best efforts) @ 1030 nm 1030 45 <λ/3 over CA €160,00
2
Ultrafast 25.4 6.35 Rs>99.9% @ 1030 nm + Tp>98% (>99% best efforts) @ 1030 nm 1030 45 <λ/4 over CA €250,00
qty 10+ > €212,50 		10+
Ultrafast 20 5 Pol@510-520 nm (Rs>99.0%, Tp>95%) 515 45 <λ/10 over 10 mm area
0
Standard 50.8 3 Tp_avg>97.5%@ 735-755 nm + Rs_avg>97.5%@ 735-755 nm 735-755 45 <λ/4 over CA €980,00
qty 5+ > €931,00 		6

If an official quotation is needed or products are not in stock, please send us a request.
Products marked as CUSTOMIZED may have a minimum order quantity rule when requesting for a quote.

In-stock items ship the next business day via DHL. Estimated delivery time: 1–2 business days (EU), 3–5 business days (Rest of World). View full shipping policy.

Need custom?

Contact OPTOMAN!
